PCRMax, Alpha cycler 1 chassis with a single 96 well block

The PCRmax Alpha cyclers are developed to deliver not only the best quality data you can expect from PCRmax but also to innovate and exceed the high standards expected by the community.

Alpha Cycler software has features such as recently used programmes; allowing users to quickly access their most commonly used protocols without the need to navigate through folders to find it, individual user logins; with protected protocols as-well-as allowing users’ access to temperature logs after each run to monitor the state of the system.

The Alpha Cycler systems also contain a novel programme wizard which allows users to define a protocol based specifically off their primer sequence and template source. Primer sequences or Tms are inputted, amplicon length and source defined and the on board algorithm generates an optimised protocol for your assay.

Technical Specifications PCRMax Alpha cycler 1 96 well block

Format: Single block
Block Options: 96 or 384 well format
Maximum heating rate: 3.4°C per second
Block temperature range: 10°C to 100°C (4°C final hold)
Block uniformity at 55°C: ± 0.3°C
Temperature accuracy at 55°C: ± 0.25°C
Gradient: Yes (on all formats)
Maximum Gradient: 29°C
Minimum Gradient: 1°C
Maximum number of programs stored: 1000
Maximum fan noise: 50dB
Type: 8 peltier elements
Adjustable heated lid temperature: 35°C to 115°C or off
Heated lid pressure: Adjustable
Program interface: 7” inch HD Android Tablet
Data transfer: USB port
Auto re-start on power failure: Yes
Dimensions (L x W x H) in mm: 430 x 260 x 200
Weight: 11.8kg
Voltage: 100-230, 50-60Hz
Power: 450W
Electricity used in a standard 2 step, 30 cycle program: 0.3 kWh
